FEATURES

• Racetech One Alloy 29er Frame
• LSG ( Longer Slacker Geometry ) Design
• 21 Speed Shimano Drivetrain
• HL Zoom Suspension Fork with Lockout
• Tektro Disc Brakes

Image module

SPECIFICATIONS

Frame Race Tech One Alloy, Exclusive LSG Design
Sizes S, M, L, XL
Fork HL Zoom Suspension, 100MM Travel, Hydraulic Lockout, Preload Adjustment
Headset Integrated Type
Stem Alloy Forged Oversize 31.8mm, S ( 60mm ), M ( 70mm ), L ( 80mm ), XL ( 90mm )
Handlebar Alloy Oversize 31.8mm, 720mm Wide
Grips Kraton MTB Closed End Dual Colour
Rotor Tektro Disc, 160MM Front and Rear
Brake Lever Shimano W/Shift Lever
Tyres Kenda MTB, 29 x 2.10, Wire Bead
Tube MTB 29 x 2.10 Schrader
Rims Alloy, Doublewall, Custom, 32H
Spokes Stainless Butted, Brass Nipples
Front Hub Alloy, 32H, Quick Release
Rear Hub Alloy, 32H, Quick Release
Chainwheel Set Forged Alloy, 42/34/24T, 175mm
Chain KMC 7-Speed
Bottom Bracket Cartridge Type
 Pedals  MTB Platform, Metal Cage
Saddle Momsen Custom
Seatpost Momsen Alloy, 31.6mm
Seat Binder Alloy Quick Release 34.9mm
Shifters Shimano EF500 21 Speed
Front Derailleur Shimano TY500
Rear Derailleur Shimano TY300
Cassette Shimano TZ21

*We reserve the right to make changes to the product information contained on this website at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

GEOMETRY

SIZE SEATTUBE LENGTH TOPTUBE EFFECTIVE HEAD ANGLE SEAT ANGLE WHEELBASE REAR CENTRE BB DROP HEADTUBE LENGTH REACH
SMALL 380 590 70.5 73 1099 450 60 110 408
MEDIUM 430 610 70.5 73 1113 450 60 110 423
LARGE 480 630 70.5 73 1134 450 60 120 440
X-LARGE  533 650 70.5 73 1154 450 60 130 457
