FEATURES

• CARBON FRAME with 142×12 Rear
• CARBON FORK with 100×12 Thru-Axle
• SRAM 1×11 GEARING
• SRAM HYDRAULIC DISC Brakes
• TYRE CLEARANCE for 700 x 45C / 650 x 50C
• STAN’S ZTR GRAIL TUBELESS Rims

Image module

SPECIFICATIONS

Frame Carbon Gravel Plus 142 x 12mm Rear Thru-Axle, Internal Cable Routing, Dropper Post Compatibility, Rear Flatmount for disc
Fork Full Carbon, Carbon Steerer, 100 x 12mm Thru-Axle, Disc Only, Flat Mount
Headset Momsen Integrated, Angular Contact Bearing
Stem Momsen 3D Forged Alloy, Oversize 31.8mm, 7 Degree Rise, 80mm ( XS, S ) 90mm ( M, L ) 100mm ( XL )
Handlebar Momsen Gravel, Oversize 31.88mm, 40cm ( XS ) 42cm ( S, M ) 44cm ( L, XL )
Grips Anti-Slip, Shockproof Tape
Rotor SRAM CLX, 6 Bolt, 160mm Front and Rear
Brake Lever Sram HRD Disc rear/Right, Front/Left
Tyres Donnelly X’plor MSO 60TPI, 700x40c Folding bead
Tube 700x40c, Presta Valve
Rims Stans ZTR Grail S1 Pro 28H / 28H
Spokes Sapim Force black
Front Hub Stan’s Neo 28H 12 x 100
Rear Hub Stan’s Neo 32H 142 x 12
Chainwheel Set Sram Force1 24mm Xsync 40T (170mm – XS, S), ( 172.5mm – M,L ), (175mm – XL)
Chain KMC X11EL-1 Lightweight
Bottom Bracket Sram Pressfit GXP ROAD 86.5/WA91.5
Saddle Fizik Aliante R5 Wingflex
Seatpost Momsen Carbon 27.2mm Comfort / 350mm
Seat Binder  Alloy 31.8mm CNC Groove
Shifters SRAM HRD 11-Speed rear only
Front Derailleur NIL
Rear Derailleur Sram force1 type long cage
Cassette Sram XG 1175 10-42T
Accessories Rubber Chainstay Protector, Metal Headbadge, Owner’s Manual
Weight 8.4kg ( Medium )

*We reserve the right to make changes to the product information contained on this website at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

GEOMETRY

SIZE SEATTUBE LENGTH TOPTUBE EFFECTIVE HEAD ANGLE SEAT ANGLE WHEELBASE REAR CENTRE BB DROP HEADTUBE LENGTH REACH STACK
X-SMALL 480 525 70.5 74.5 1033 450 85 115 369 564
SMALL 500 545 70.5 73.2 1039 450 82.5 135 370 581.5
MEDIUM 520 560 71.25 73.2 1049 450 82.5 150 380 598
LARGE  540 575 71.25 73 1069 450 80 165 388 609
X-LARGE  560 590 71.25 73 1079 450 80 185 397 628
