FEATURES:

  • VIPA FULL CARBON 120MM Full Suspension
  • ROCKSHOX REBA Boost 110 x 15 Suspension Fork
  • SRAM NX Eagle 12 Speed
  • FOX FLOAT DPS Rear Shock
Image module

SPECIFICATIONS

Frame Full Carbon Trail, 120Mm Rear Travel, Boost 148 Spacing, Internal Cable Routing
Fork Rockshox Reba Rl, Boost 110, 15Mm Thru-Axle, 120Mm Travel, Rebound Adjust
Rear Shock Fox Float DPS, Performance Series, 3 Position Adjust, Evol
Headset Taper Integrated Type
Stem Alloy Enduro Oversize 31.8mm, S ( 60mm ), M ( 70mm ), L ( 80mm ), XL ( 90mm )
Handlebar Alloy Enduro Oversize 31.8mm, 12mm Rise, 720mm Wide
Grips Kraton MTB Lock-On
Rotor Shimano RT-54 Centerlock, 180mm Front and 160mm Rear
Brake Lever Shimano MT500 Hydraulic
Tyres Vee Tire Co. Rail Tracker 29 x 2.20, 27TPI
Tube Kenda 29 x 2.10 Presta
Rims Alex/Momsen Custom DP25, Tubeless Ready, 32H
Spokes Stainless Butted, Brass Nipples
Front Hub Shimano M6010 Boost Centerlock / 15mm Thru-Axle
Rear Hub Shimano M6010 Boost Centerlock / 148 x 12 Thru-Axle
Chainwheel Set SRAM Nx Boost 12-Speed, 32T, 175mm
Chain SRAM 12-Speed
Bottom Bracket SRAM GXP Pressfit Dub
Saddle Momsen Custom
Seatpost Momsen Alloy, 31.6mm
Seat Binder Alloy Quick Release 34.9mm
Shifters SRAM NX Eagle 12 Speed
Front Derailleur Nil
Rear Derailleur SRAM NX Eagle 12-Speed
Cassette SRAM NX Eagle 12-Speed 11-50T
Accessories Rubber Chainstay Protector, Metal Headbadge, Owner’s Manual
Weight 13.13kg ( Medium )

*We reserve the right to make changes to the product information contained on this website at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

GEOMETRY

Image module
SIZE SEATTUBE LENGTH TOPTUBE EFFECTIVE HEAD ANGLE SEAT ANGLE WHEELBASE REAR CENTRE BB DROP HEADTUBE LENGTH REACH STACK
SMALL 394 562 67.8 73.5 1105 440 39 95 387 589
MEDIUM 445 583 67.8 73.5 1128 440 39 105 405 599
LARGE 483 603 67.8 73.5 1149 440 39 115 422 608
X-LARGE  533 633 67.8 73.5 1180 440 39 125 450 618
