FEATURES:

  • ALLOY VIPA 120MM Suspension Frame
  • ROCKSHOX Air Suspension Fork
  • FOX Rear Suspension
  • SRAM GX Eagle 12 Speed
  • BOOST Front and Rear
Image module

SPECIFICATIONS

Frame Alloy trail, 120mm Rear travel, Boost 148 spacing, Internal cable routing
Fork Rockshox Judy Gold RL, Boost 110, Remote, 15mm Thru-axle, 120mm Travel
Rear Shock Fox float DPS, Performance series, 3 position adjust, Evol
Headset Taper Integrated Type
Stem Alloy Enduro Oversize 31.8mm, S ( 60mm ), M ( 70mm ), L ( 80mm ), XL ( 90mm )
Handlebar Alloy Enduro Oversize 31.8mm, 12mm Rise, 720mm Wide
Grips Kraton MTB Lock-On
Rotor Shimano RT-64 Centerlock, 180mm Front and 160mm rear
Brake Lever Shimano MT-500
Tyres Maxxis Ardent race 29 x 2.20 Front, IKON 29 x 2.20 Rear, EXO/TR 60TPI
Tube Kenda 29 x 2.10 Presta
Rims Alex/Momsen Custom DP25, Tubeless Ready, 32H
Spokes Stainless Butted, Brass Nipples
Front Hub Alloy, Disc, Boost 110, Centerlock
Rear Hub Alloy, XD Driver, Disc, Boost 148, Centerlock
Chainwheel Set SRAM GX Eagle, B148, DUB, 32T, 175mm
Chain SRAM NX Eagle, 12 Speed
Bottom Bracket SRAM DUB Pressfit
Saddle Selle Royal Seta S1 Custom
Seatpost Momsen Alloy, 31.6mm
Seat Binder Alloy, Bolt type, 34.9mm
Shifters SRAM GX Eagle Trigger, 12 Speed
Front Derailleur Nil
Rear Derailleur SRAM GX Eagle
Cassette SRAM XG-1275 Eagle, 10-50T
Accessories Rubber Chainstay Protector, Metal Headbadge, Owner’s Manual
Weight 13.8kg ( Medium )

*We reserve the right to make changes to the product information contained on this website at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

GEOMETRY

Image module
SIZE SEATTUBE LENGTH TOPTUBE EFFECTIVE HEAD ANGLE SEAT ANGLE WHEELBASE REAR CENTRE BB DROP HEADTUBE LENGTH REACH STACK
SMALL 394 562 67.8 73.5 1105 440 39 95 387 589
MEDIUM 445 583 67.8 73.5 1128 440 39 105 405 599
LARGE 483 603 67.8 73.5 1149 440 39 115 422 608
X-LARGE  533 633 67.8 73.5 1180 440 39 125 450 618
