FEATURES
- Racetech Two Frame, LSG Design, I.T.B Ready
- SR Suntour Xct30 Suspension, 100mm Travel, Lockout Feature
- Shimano 2 X 8 Drivetrain
- Maxxis Ikon 29 X 2.20 Tyres
SPECIFICATIONS
| Frame | Race Tech Two Alloy, Exclusive LSG Design,Integrated Toptube Box (I.T.B) |
| Sizes | S, M, L, XL |
| Fork | SR Suntour XCT30, 100mm Travel, Hydraulic Lockout, Preload Adjustment |
| Headset | Integrated Type |
| Stem | Alloy Forged Oversize 31.8MM, S (60mm), M (70mm), L (80mm), XL (90mm) |
| Handlebar | Alloy Oversize 31.8MM, 720mm Wide |
| Grips | Kraton MTB Closed End Dual Colour |
| Rotor | Tektro Disc, 160mm Front and Rear |
| Brake Lever | Tektro M275 Hydraulic |
| Tyres | Maxxis Ikon 29 X 2.20 , Wire Bead |
| Tube | Kenda 29 X 2.10 Presta |
| Rims | Weinmann XTB26, Alloy, Doublewall, Custom, 32H |
| Spokes | Stainless Butted, Brass Nipples |
| Front Hub | Alloy for Disc, 32H |
| Rear Hub | Alloy For Disc, 32H |
| Chainwheel Set | Shimano M315 Alloy, 36/22T, 170mm |
| Chain | KMC 8 Speed |
| Bottom Bracket | Cartridge Type |
| Pedals | MTB Platform, Metal Cage |
| Saddle | Momsen Custom |
| Seatpost | Momsen Alloy, 31.6mm |
| Seat Binder | Alloy Quick Release type |
| Shifters | Shimano M315 Trigger for 2 x 8 Speed |
| Front Derailleur | Shimano M315 |
| Rear Derailleur | Shimano Altus M310 |
| Cassette | Shimano HG200-8 12-32T |
| Accessories | Rubber Chainstay Protection, Metal Headbadge, Owner’s manual |
| Weight | 14.11 Kg (Excl. Pedals) |
*We reserve the right to make changes to the product information contained on this website at any time without notice, including with respect to equipment, specifications, models, colors, and materials.
GEOMETRY
| SIZE | A: SEATTUBE LENGTH | B: TOPTUBE EFFECTIVE | C: HEAD ANGLE | D: SEAT ANGLE | E: WHEELBASE | F: REAR CENTRE | G: BB DROP | H: HEADTUBE LENGTH | I: REACH |
| SMALL | 380 | 590 | 70.5 | 73 | 1099 | 450 | 60 | 110 | 408 |
| MEDIUM | 430 | 610 | 70.5 | 73 | 1113 | 450 | 60 | 110 | 423 |
| LARGE | 480 | 630 | 70.5 | 73 | 1134 | 450 | 60 | 120 | 440 |
| X-LARGE | 533 | 650 | 70.5 | 73 | 1154 | 450 | 60 | 130 | 457 |
SIZING
| Height in CM | Frame Size |
| 155-165 | S |
| 165-175 | M |
| 175-187 | L |
| 187-197 | XL |
