FEATURES

  • Updated to 100mm Travel
  • Boost 148 Spacing
  • Integrated Storage Solution
  • Progressive Modern Geometry
  • Integrated Dual Bottle Capability ( 2 x 750ml on Medium Size )
  • Low Front End / Headtube
  • Flip Chip for Stage Race vs XCO Racing
  • Threaded 73mm Bottom Bracket
  • Compatible with both 1x and 2x Drivetrains
  • Frame-Kit includes : Frame / Rear Shock / Seatclamp / Headset / 2 x Stems / Rear Axle / Toptube Bag / Downtube Cover / Downtube Protector / Chainstay Protector

The frame comes in TWO sizes. Please check the Sizing chart and Geometry below for the correct size for you.

Image module

SPECIFICATIONS

Frame Full Carbon Front and Rear Triangle, Toray T1000 with T800 / T700 Mix
Rear Shock Fox Float Performance Series, Trunnion Mount, 185 x 50mm, Light Rebound, Firm Lockout Mode
Suggested Fork Travel 100mm or 120mm with selection of either 51mm or 44mm Offset
Standard Seatpost 31.6 Diameter
Dropper Seatpost 31.6 Diameter / Maximum 125mm Drop / Internal Routing
Bottom Bracket Threaded 73mm BSA
Front Derailleur Compatibility Direct Mount for 2x Drivetrains ( Note: Tab can be removed for 1x )
Rear Hub Spacing 148mm / 12mm Axle
Suggested Tyre Size 1.95 to 2.35 Width ( Note: Various Tyre Brands measure differently )
Suggested Rim Size 19mm to 23mm Internal
Headset FSA No.42 / 42mm Upper and 52mm Lower Bearing
Crankset Compatibility – Sram Sram XX1 Boost 148 / 36T Maximum Size ( 3mm Clearance )
Crankset Compatibility – Shimano Shimano 36/26T 148 or 1×12 with 34T Maximum Size
Rear Brake 160mm Postmount

GEOMETRY

FRAME SIZE SEAT TUBE TT LENGTH HT ANGLE ST ANGLE FORK LENGTH FORK OFFSET WHEELBASE REAR CENTER BB DROP HT LENGTH REACH STACK STEM LENGTH SPEC
SIZE 01(Front Pos. Flip Chip) 432 610 68.5 74 507 51 1156 440 40 90 451.1 577 40
SIZE 02(Front Pos. Flip Chip) 510 628 68 74.6 507 51 1181 440 40 110 465 593 40

SIZING

THE ULTRA IS AVAILABLE IN 2 FRAME SIZES

WE’RE NOT CALLING THEM MEDIUM OR LARGE BUT RATHER SIZE 01 AND SIZE 02. WHY?
With our progressive geometry and a modern take on endurance bike design, we believe that having a longer front end combined with the right angles and overall geometry can allow you to select a bike based on a parameter other than just seat tube length.

With the advent of dropper seatposts, allowing longer seatpost extensions and easy adjustment, the seat-tube length is less of a driving factor and riders should consider things like reach and overall toptube length before selecting the good old SIZE M bike.

NOTE: Should you be in the “grey area” between frame sizes, we recommend going with the Longer Frame Size for both performance and comfort.



SIZE TABLE

YOUR HEIGHT(CM) SIZE 01 SIZE 02
162 – 175 •
174 – 190 •
