FEATURES

  • Rock Shox REBA RL 100mm Taper Steerer
  • Shimano XT/SLX 10-Speed Groupset
  • ZTR Crest 29er Rims with Shimano SLX Hubs
  • Shimano PD-M520 Clipless Pedals
  • Continental X-King 2.4 Fr, X-King 2.2 Rr Tyres
  • Shimano M596 Disc Brakes

SPECIFICATIONS

Frame Race Tech 2, Alloy 6061 Butted Tubeset
Sizes Small, Medium, Large, X-Large
Fork Rock Shox REBA RL, QR, Taper Crown
Chainwheel Shimano M522 Deore 42/32/24T
Bottom Bracket Shimano ES25
F. Derailleur Shimano SLX
R. Derailleur Shimano XT, Shadow
Shifter Shimano SLX
Brake Levers Shimano M596 Hydraulic
Brakes Shimano M596 Hydraulic
Cassette Shimano HG62, 11-34T
Rims Stan’s No Tubes ZTR Crest 29, 32H
Tires Continental X-King 2.4 Front, Race King 2.2 Rear
Pedals Shimano M520 Clipless
Handlebar New Alloy Flat Top 29er, 680mm, 31.8mm Oversize
Stem New Alloy 3D Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat New Momsen Race Cromo Rail
Headset FSA No 42 for Taper, Alloy
Colors Gloss Grey with Red Details
Chain Shimano HG54 10 Speed
Hubset Shimano SLX, 32h
Spokes Butted 2.0/1.8 Stainless Black 14g, Red Alloy Nipples
Grips New Momsen Lock-On
Extras Stan’s No Tubes Tubeless Kit
Weight 11.87kg ( Medium, Excl. Pedals )

GEOMETRY

SIZE SMALL MEDIUM LARGE XL
(A) Seat Tube Length  406  430  480  533
(B) Top Tube Effective  585  595  615  630
(C) Head Tube Angle  71°  71.5°  71.5°  71.5°
(D) Seat Tube Angle  73.5°  73°  73°  73°
(E) Wheelbase  1086  1088  1107  1122
(F) Rear Center  450  450  450  450
(G) BB Drop  60  60  60  60
(H) Head Tube Length  110  110  110  120
