FEATURES

  • Suntour XCM RL Suspension with Remote Lockout Lever
  • Shimano 27 Speed Gear System with SLX Rear Derailleur
  • Tektro Hydraulic Disc Brakes
  • Shimano Crankset 42/32/22 Triple Chainring
  • Shimano Centerlock Hubs with Weinmann ZAC2000 Rims

SPECIFICATIONS

Frame Race Tech 1, Alloy 6061 Tubeset
Sizes Small, Medium, Large, X-Large
Fork SR Suntour XCM RL, Remote Lockout Lever
Chainwheel Shimano M361 42/32/22T
Bottom Bracket Cartridge Type
F. Derailleur Shimano Acera
R. Derailleur Shimano SLX
Shifter Shimano M390 Trigger Type
Brake Levers Tektro Draco Hydraulic
Brakes Tektro Draco Hydraulic
Cassette Shimano HG20 Cassette, 11-32T
Rims Weinmann ZAC2000, 32H
Tires Kenda Small Block Eight 26 x 2.10 60tpi
Pedals Alloy Platform Type
Handlebar Alloy Riser, 31.8mm Oversize
Stem Alloy Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat SR Seat
Headset Ahead Type, 1.1/8″
Colors Matte Black w/Red Details
Chain KMC 9 Speed
Hubset Shimano Centerlock, 32h
Spokes Stainless Steel
Grips Kraton Comfort
Weight 14.4kg ( Medium )

GEOMETRY

SIZE SMALL MEDIUM LARGE XL
(A) Seat Tube Length  381  432  483  533
(B) Top Tube Effective  542  573  595  610
(C) Head Tube Angle  71°  71°  71°  70.5°
(D) Seat Tube Angle  72.5°  72.5°  72.5°  72.5°
(E) Wheelbase  1018  1050  1073  1093
(F) Rear Center  425  425  425  425
(G) BB Drop  32  32  32  32
(H) Head Tube Length  115  125  135  155
