FEATURES

  • Custom Lady Specific 29er Frame Design
  • Custom RockShox XC 32 Fork with 51mm Offset and Alloy Steerer Tube
  • Fizik Vitesse Lady Specific Saddle
  • Tektro Draco WS ( Women Specific ) Hydraulic Brakes
  • Shimano PD-M505 Clipless Pedals
  • Shimano M542 External BB Crankset
  • Stan’s No Tubes ZTR Crest Rims with Shimano Hubs
  • Shimano HG30 Cassette 11-34t
  • Kenda Karma 1.95 Lightweight Tyres
  • Lighter Handlebar and Stem
  • Lock-On Grips

SPECIFICATIONS

Frame Race Tech 2, Alloy 6061 Butted Tubeset
Sizes X-Small, Small, Medium
Fork RockShox XC32, 51mm Offset, Turnkey Lockout
Chainwheel Shimano M542 Deore 44/32/22T
Bottom Bracket Shimano External Type
F. Derailleur Shimano Alivio
R. Derailleur Shimano SLX, Shadow
Shifter Shimano Alivio
Brake Levers Tektro Draco WS Women Specific Lever
Brakes Tektro Draco WS Women Specific Lever
Cassette Shimano HG30, 11-34T
Rims Stan’s No Tubes ZTR Crest 29, 32H
Tires Kenda Karma 1.95
Pedals Shimano M505 Clipless
Handlebar New Alloy Flat Top 29er, 680mm, 31.8mm Oversize
Stem New Alloy 3D Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Fizik Vitesse Women
Headset FSA No 42 for Taper, Alloy
Colors Flat Black w/Blue Details
Chain Shimano HG53 9 Speed
Hubset Shimano M475, 32h
Spokes Butted 2.0/1.8 Stainless Black 14g, Red Alloy Nipples
Grips New Momsen Lock-On
Extras Stans No Tubes Tubless Kit
Weight 12.26kg ( Medium, Excl. Pedals )

GEOMETRY

SIZE X-SMALL SMALL MEDIUM
(A) Seat Tube Length  381  406  432
(B) Top Tube Effective  575  585  595
(C) Head Tube Angle  70.5°  70.5°  71°
(D) Seat Tube Angle  73.5°  73.5°  73°
(E) Wheelbase  1077  1083  1085
(F) Rear Center  440  440  440
(G) BB Drop  62.5  62.5  62.5
(H) Head Tube Length  90  90  100
