FEATURES

  • Race Tech SL, High Modulus Carbon Frame
  • Shimano XT 2 x 10 Groupset
  • RockShox SID RL with PushLoc Remote Lockout
  • ZTR Crest Rims with Sun Ringle Hubs
  • FIZIK Tundra 2 Saddle

SPECIFICATIONS

Frame Race Tech SL, High Modulus Carbon, UD Finish
Sizes Small ,Medium, Large
Fork RockShox SID RLT, Pushloc Remote
Chainwheel Shimano XT M785, 38/26T
Bottom Bracket Shimano XT included with Chainwheel
F. Derailleur Shimano XT
R. Derailleur Shimano XT
Shifter Shimano XT
Brake Levers Shimano XT
Brakes Shimano XT
Cassette Shimano M771 10 Speed, 11-36T
Rims Stan’s No Tubes ZTR Crest 29, 32H
Tires Kenda 24Seven Race 29 x 2.1 Folding Bead
Pedals Shimano M520 Clipless
Handlebar New Alloy Flat Top 29er, 680mm, 31.8mm Oversize
Stem FSA OS-150LX, 6 Degree
Seatpost New Momsen 3D Forged Alloy Micro-Adjust
Seat Fizik Tundra 2 Kium
Headset FSA No 42 for Taper, Alloy
Colors Gloss White w/Red Details
Chain Shimano HG74 XT 10 Speed
Hubset Sun Ringle Dirty Flea
Spokes Butted 2.0/1.8 Stainless Black 14g, Red Alloy Nipples
Grips New Momsen Foam Lock-On
Extras Stan’s No Tubes Tubeless Kit
Weight 10.880kg ( Medium, Excl. Pedals )

GEOMETRY

SIZE SMALL MEDIUM LARGE
(A) Seat Tube Length  420  480  530
(B) Top Tube Effective  600  620  640
(C) Head Tube Angle  71.5°  72°  72°
(D) Seat Tube Angle  73.5°  73°  73°
(E) Wheelbase  1087  1097  1117
(F) Rear Center  440  440  440
(G) BB Drop  60  60  60
(H) Head Tube Length  110  120  130
