FEATURES

  • Race Tech 2 Road Spec Frame. Lightweight Butted Tubing Optimized For Road. Internal Toptube Cable Routing.
  • Carbon Fork, Alloy Steerer. Aero Profile Carbon Lower Legs. Lightweight Alloy Steerer.
  • Shimano Tiagra Crankset. Arguably The Best Crankset At This Pricepoint.
  • Shimano Tiagra Derailleurs. A firm favourite. Precise. Durable.
  • Shimano WH-R501 Wheelset. The Best Entry Level Complete Wheel System On The Market. Aero Bladed Spokes. 20 / 24 Hole Lacing Pattern.

SPECIFICATIONS

Frame Race Tech 2, Road Spec
Sizes 45 / 48 /50 / 52 / 54 / 57
Fork Carbon Blade, Alloy Steerer
Chainwheel Shimano Tiagra 50/34T
Bottom Bracket Shimano HollowTech
F. Derailleur Shimano Tiagra
R. Derailleur Shimano Tiagra 10 Speed
Shifter Shimano Tiagra
Brake Levers Tektro Alloy Dual Caliper
Brakes Tektro Alloy Dual Caliper
Cassette Shimano Tiagra, 12-28T
Rims Shimano WH-R501
Tires Kenda K191 700 x 23C
Pedals Alloy Cage w/Clips
Handlebar Alloy Flat Top, 31.8mm Oversize
Stem Alloy Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Momsen Race
Headset Ahead Threadless Type
Colors Glossy White w/Red Details
Chain Shimano CN-4601 Speed
Hubset w/Shimano Wheels
Spokes w/Shimano Wheels
Grips Gum Wrap Red
Weight 9.15 kg ( Medium, Excl Pedals )

GEOMETRY

SIZE SMALL MEDIUM LARGE XL LARGE XL
(A) Seat Tube Length  450  480  500  520  540  570
(B) Top Tube Effective  518  537  548  565  580  600
(C) Head Tube Angle  72°  72°  72°  72.5°  72.5°  73°
(D) Seat Tube Angle  75.5°  74°  73.5°  73.2°  73°  73°
(E) Wheelbase  979  985  996  1006  1022  1032
(F) Rear Center  412  412  415  415  418  418
(G) BB Drop  73  73  71.5  71.5  70  70
(H) Head Tube Length  110  130  150  175  200  220
