FEATURES

  • SRAM 3 X 10 DRIVETRAIN. 30 SPEED.
  • RACE TECH 2 BUTTED FRAME TUBING
  • TEKTRO HYDRAULIC DISC BRAKE SYSTEM
  • SUN RINGLE INFERNO 23 RIMS

SPECIFICATIONS

Frame Race Tech 2, Alloy 6061 Butted Tubeset
Sizes Small, Medium, Large, X-Large
Fork Suntour SR XCM, 100mm, Hydraulic Lockout
Chainwheel SRAM S800 44/32/22T
Bottom Bracket SRAM PowerSpline
F. Derailleur SRAM X5
R. Derailleur SRAM X5 10 Speed
Shifter SRAM X5 Trigger
Brake Levers Tektro HDC 300 Hydraulic
Brakes 160 Fr /160 Rr
Cassette SRAM PG1030 – 11-36T
Rims Sun Ringle Inferno  23, 32H
Tires Kenda Small Block Eight Wire Bead 29 x 2.10
Pedals Wellgo Platform Alloy
Handlebar Alloy Riser – 640mm x 15mm Rise – 31.8mm Oversize
Stem Alloy Forged – 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Momsen Race
Headset Alloy Threadless
Colors Matte Blue w/White Details
Chain KMC 10 Speed
Hubset SRAM 406H – 32h
Spokes Stainless Butted with Alloy Nipples
Grips Kraton Comfort
Weight 13.80 kg ( Medium, Excl Pedals )

GEOMETRY

SIZE SMALL MEDIUM LARGE XL
(A) Seat Tube Length  406  430  480  533
(B) Top Tube Effective  585  595  615  630
(C) Head Tube Angle  71°  71.5°  71.5°  71.5°
(D) Seat Tube Angle  73.5°  73°  73°  73°
(E) Wheelbase  1086  1088  1107  1122
(F) Rear Center  450  450  450  450
(G) BB Drop  60  60  60  60
(H) Head Tube Length  110  110  110  120
