FEATURES

  • RockShox XC 32 AIR Suspension Fork 100mm
  • RockShox PopLoc Remote Handlebar Lockout
  • RaceTech 2, 2nd Generation Frame Design with 27.2mm Seatpost
  • Schwalbe Racing Ralph SNAKESKIN Tubeless Tyres
  • Stan’s ZTR ARCH EX Tubeless Rims

SPECIFICATIONS

Frame Race Tech 2, 2nd Generation Frame Design, Alloy 6061 Butted Tubeset
Sizes Small ,Medium, Large, X-Large
Fork RockShox XC32 Solo Air with Remote Lockout 100mm
Chainwheel SRAM S800 44/32/22T
Bottom Bracket SRAM PowerSpline
F. Derailleur SRAM X5
R. Derailleur SRAM X7 10 Speed
Shifter SRAM X5 Trigger
Brake Levers Avid Elixir 1
Brakes 160 Fr /160 Rr
Cassette SRAM PG1030 – 11-36T
Rims No Tubes ZTR Arch EX -32H
Tires Schwalbe Racing Ralph SNAKESKIN Tubeless 29 x 2.25
Pedals Wellgo Platform Alloy
Handlebar Alloy Riser – 640mm x 15mm Rise – 31.8mm Oversize
Stem Alloy Forged – 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Momsen Race
Headset Alloy Taper
Colors Matte Black w/Blue Details
Chain KMC 10 Speed
Hubset SRAM 406H – 32h
Spokes Stainless Butted with Alloy Nipples
Grips Silicone Race
Weight 12.76 kg ( Medium, Excl Pedals, W/Tubeless Tyres )

GEOMETRY

SIZE SMALL MEDIUM LARGE XL
(A) Seat Tube Length  406  430  480  533
(B) Top Tube Effective  585  595  615  630
(C) Head Tube Angle  71°  71.5°  71.5°  71.5°
(D) Seat Tube Angle  73.5°  73°  73°  73°
(E) Wheelbase  1086  1088  1107  1122
(F) Rear Center  450  450  450  450
(G) BB Drop  60  60  60  60
(H) Head Tube Length  110  110  110  120
