FEATURES

  • WOMEN SPECIFIC 29er FRAME DESIGN – XS / SMALL / MEDIUM SIZES
  • ROCKSHOX XC32 SUSPENSION FORK WITH 51MM OFFSET
  • WOMEN SPECIFIC COMFORT SADDLE
  • WOMEN SPECIFIC TEKTRO HYDRAULIC BRAKES
  • SCHWALBE RACING RALPH FOLDING BEAD TYRES

SPECIFICATIONS

Frame Race Tech 2, Alloy 6061 Butted Tubeset, Lady Specific Geometry
Sizes X-Small, Small, Medium
Fork RockShox XC32, 51mm Offset, Turnkey Lockout
Chainwheel SRAM X5 44/32/22T
Bottom Bracket SRAM GXP
F. Derailleur SRAM X5
R. Derailleur SRAM X5 9 Speed
Shifter SRAM X5 Trigger
Brake Levers Tektro Women Specific
Brakes 160 Fr /160 Rr
Cassette Shimano HG30, 11-34T
Rims Sun Ringle Inferno, 32H
Tires Schwalbe Racing Ralph Folding Bead 29 x 2.10
Pedals Wellgo Platform Alloy
Handlebar Alloy Riser , 640mm x 15mm Rise, 31.8mm Oversize
Stem Alloy Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Selle Royal Seta Lady
Headset Alloy Taper
Colors Matte Black w/Blue Details
Chain Shimano HG53
Hubset SRAM 406H – 32h
Spokes Stainless Butted with Alloy Nipples
Grips Silicone Race
Weight 12.90 kg ( Medium, Excl Pedals )

GEOMETRY

SIZE X-SMALL SMALL MEDIUM
(A) Seat Tube Length  381  406  432
(B) Top Tube Effective  575  585  595
(C) Head Tube Angle  70.5°  70.5°  71°
(D) Seat Tube Angle  73.5°  73.5°  73°
(E) Wheelbase  1077  1083  1085
(F) Rear Center  440  440  440
(G) BB Drop  62.5  62.5  62.5
(H) Head Tube Length  90  90  100
