FEATURES

  • Race Tech SL Carbon Frame. Cape-Epic Proven
  • Rockshox Recon Silver Suspension Fork. Air Adjust
  • SRAM 3 X 10 Drivetrain
  • Sun Ringle Inferno 23 Rims
  • Schwalbe Racing Ralph Folding Bead Tyres

SPECIFICATIONS

Frame Race Tech SL Carbon
Sizes Small ,Medium, Large
Fork RockShox Recon Silver Turnkey Lockout 100mm
Chainwheel SRAM S800 44/32/22T
Bottom Bracket SRAM PowerSpline
F. Derailleur SRAM X5
R. Derailleur SRAM X7 10 Speed
Shifter SRAM X5 Trigger
Brake Levers Avid Elixir 1
Brakes 160 Fr / 160 Rr
Cassette SRAM PG1030 – 11-36T
Rims Sun Ringle Inferno – 32H
Tires Schwalbe Racing Ralph Folding Bead 29 x 2.10
Pedals Shimano M505 Clipless
Handlebar Alloy Riser – 640mm x 15mm Rise – 31.8mm Oversize
Stem Alloy Forged – 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Momsen Race
Headset Alloy Taper
Colors Matte White w/Orange Details
Chain KMC 10 Speed
Hubset SRAM 406H – 32h
Spokes Stainless Butted with Alloy Nipples
Grips Silicone Race
Weight 12.17kg ( Small, without pedals )

GEOMETRY

SIZE SMALL MEDIUM LARGE
(A) Seat Tube Length  420  480  530
(B) Top Tube Effective  600  620  640
(C) Head Tube Angle  71.5°  72°  72°
(D) Seat Tube Angle  73.5°  73°  73°
(E) Wheelbase  1087  1097  1117
(F) Rear Center  440  440  440
(G) BB Drop  60  60  60
(H) Head Tube Length  110  120  130
