FEATURES

  • Race Tech SL+ Carbon Frame. Cape-Epic Race Tested And Proven, Superlight At Just 1020g ( Medium ) With Syntace 142 x 12MM Rear Axle. Taper Headtube, Internal Cable-Routing, BB92 Press Fit
  • Rockshox Sid XX World Cup Suspension. Fork What The Pro’s Use To Win. Carbon Upper Assembly, XX Hydraulic Remote Lockout, 15MM Thru-Axle. 100MM Travel. The Best.
  • Fizik Gobi Saddle. A Popular Aftermarket Choice. Light And Comfortable. Standard On This Bike.
  • Stan’s No Tubes ZTR Arch Ex Wheelset. The Best ‘All-Rounder’ Rim In The Lightweight No Tubes ZTR ( Zero Tube Rim ) Range. The Arch Design Provides Increased Sti‑ness Whilst Still O‑ering A Very Low Weight. A Popular Upgrade On Many 29ers Standard On Our Bike.
  • Sram XX 2 X 10 Drivetrain With XX Gripshift. A Popular Choice At The Leading Edge Of The World Cup XCO And Marathon Series. The Standard By Which All Other 2 x 10 Drivetrains Are Measured. Light. New Gripshift Features Ball Bearing Construction. Smooth, Fast Action.
  • Schwalbe Racing Ralph Snakeskin Tyres. Already A Firm Favourite In The Aftermarket, We Have Specced These Full Tubeless Tyres Complete with The German Brand’s “Snakeskin” Sidewalls. A Tougher Sidewall, A Proper Tubeless Design And A Low Weight. Bliss.

SPECIFICATIONS

Frame Race Tech Carbon SL+
Sizes Small ,Medium, Large, X-Large
Fork RockShox SID XX World Cup 15mm Thru-Axle – 100mm
Chainwheel SRAM XX 39/26
Bottom Bracket SRAM GXP PressFit
F. Derailleur SRAM XX
R. Derailleur SRAM XX 10 Speed
Shifter SRAM XX Gripshift
Brake Levers SRAM XX
Brakes 160 Fr / 160 Rr
Cassette SRAM PG1099 – 11-36T
Rims No Tubes ZTR Arch EX – 32H
Tires Schwalbe Racing Ralph SNAKESKIN Tubeless 29 x 2.25
Pedals N/A
Handlebar Truvative Noir Carbon 700 Flat
Stem Alloy 3D Forged Superlight – 31.8mm Oversize
Seatpost Easton EC90 Carbon 27.2
Seat Fizik Gobi XM
Headset FSA No 42 Carbon Taper
Colors Matte Carbon w/White Details
Chain KMC 10 Speed Superlight Ti-Gold
Hubset SRAM X9 15mm Fr – SRAM X9 142 x 12 Rr – 32h
Spokes Stainless Butted with Alloy Nipples
Grips Silicone Race
Weight 9.60kg (Medium Excl. Pedals)

GEOMETRY

SIZE SMALL MEDIUM LARGE XL
(A) Seat Tube Length  380  430  480  530
(B) Top Tube Effective  580  603  622  639
(C) Head Tube Angle  71°  71.5°  71.5°  71.5°
(D) Seat Tube Angle  74°  74.2°  74.2°  74.2°
(E) Wheelbase  1074  1089  1108  1125
(F) Rear Center  438  438  438  438
(G) BB Drop  62  62  62  62
(H) Head Tube Length  100  105  110  125
