FEATURES

  • 2nd Generation 29er Race Tech Frame – 27.2 Post, 450mm Stays. Our Newest 29er Alloy Frame – Revised 27.2mm Seatpost For Added Compliance And Comfort. Revised Race Geometry. Shorter Chainstays.
  • Stan’s ZTR Rapid Wheelset. Tubeless Ready Rims. Lighter Than Most Aftermarket Upgrade As Standard Equipment.
  • Taper Headtube. A Huge Upgrade In Front End Stiffness. Apart From Performance Benefits Associated With The Oversize 1.1/8” To 1.5” Taper Tube For Strength.
  • Shimano 30-Speed Deore Groupset. Popular And Proven Components. Light, Precise, Perfect.
  • Suntour Raidon XC RL Air Suspension Fork With Remote Lockout. Air Damping Allows A Larger Range Of Adjustment. Remote Handlebar Lockout Lever Offers Easy On / Off Adjustment

SPECIFICATIONS

Frame 2nd Generation Race Tech 2, Alloy 6061 Butted Tubeset
Sizes Small ,Medium, Large, X-Large
Fork Suntour SR RAIDON XC RL, AIR, 100mm, Remote Lockout Lever
Chainwheel Shimano M522 42/32/24T
Bottom Bracket Shimano ES25 Octalink
F. Derailleur Shimano Deore
R. Derailleur Shimano Deore 10 Speed
Shifter Shimano Deore Trigger
Brake Levers Shimano M395 Hydraulic
Brakes 160 Fr /160 Rr
Cassette Shimano HG62, 11-36T
Rims Stan’s ZTR Rapid 29er Tubeless Ready, 32H
Tires Kenda Slant Six, Folding Bead, 29 x 2.0
Pedals Wellgo Alloy
Handlebar Alloy Riser , 640mm x 15mm Rise, 31.8mm Oversize
Stem Alloy Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Selle Royal Seta S1 Custom
Headset Alloy Taper
Colors Gunmetal Grey w / Green Details
Chain KMC 10 Speed
Hubset Shimano SLX, 32h
Spokes Stainless Butted with Alloy Nipples
Grips Kraton Race
Weight 12.82kg (Medium, Excl. Pedals)

GEOMETRY

SIZE SMALL MEDIUM LARGE XL
(A) Seat Tube Length  406  430  480  533
(B) Top Tube Effective  585  595  615  630
(C) Head Tube Angle  71°  71.5°  71.5°  71.5°
(D) Seat Tube Angle  73.5°  73°  73°  73°
(E) Wheelbase  1086  1088  1107  1122
(F) Rear Center  445  445  445  445
(G) BB Drop  60  60  60  60
(H) Head Tube Length  110  110  110  120
