FEATURES

  • 2nd Generation 29er Race Tech Frame – 27.2 Post, 450mm Stays. Our Newest 29er Alloy Frame – Revised 27.2mm Seatpost For Added Compliance And Comfort. Revised Race Geometry. Shorter Chainstays.
  • Stan’s ZTR Crest 29er Wheelset With Shimano SLX Hubs. Popular Upgrade Wheels For 29er. Light But Durable. Race Wheels On A Budget.
  • Ritchey Cockpit. Premium Brand Of Aftermarket Components. Light And Durable.
  • Sram X9 / X7 3 x 10 Drivetrain. The Wildest Range Of Gearing To Make Your Riding As Fun As Possible. Huge 11 – 36 Tooth Cassette Sprocket. More Options. More Fun.
  • Rockshox Reba RL Suspension Fork 100mm. The “Work Horse” Race Level RockShox Suspension Fork. 100mm Travel, Rebound Adjust And Turnkey Lockout.

SPECIFICATIONS

Frame 2nd Generation Race Tech 2, Alloy 6061 Butted Tubeset
Sizes Small ,Medium, Large, X-Large
Fork RockShox REBA RL , Lockout, 100mm Travel
Chainwheel SRAM S1000 44/32/22T
Bottom Bracket SRAM GXP External
F. Derailleur SRAM X7
R. Derailleur SRAM X9 TYPE 2 10 Speed
Shifter SRAM X5 Trigger
Brake Levers Shimano M596 Hydraulic
Brakes Shimano M596 Hydraulic
Cassette SRAM PG1030, 11-36T
Rims Stan’s No Tubes ZTR Crest, 32H
Tires Kenda Slant Six, Folding Bead, 29 x 2.0
Pedals Shimano M505 Clipless
Handlebar Ritchey COMP 2x , 720mm, 31.8mm Oversize
Stem Ritchey 4-Axis, 31.8mm Oversize
Seatpost Ritchey COMP 2 Bolt, 27.2
Seat Selle Royal Seta S1 Custom
Headset Alloy Taper Integrated
Colors Fast Black w/Red and Blue Details
Chain KMC 10 Speed
Hubset Shimano SLX, 32h
Spokes Stainless Butted with Alloy Nipples
Grips Kraton Race
Weight 11.82kg (Medium, Excl. Pedals)

GEOMETRY

SIZE SMALL MEDIUM LARGE XL
(A) Seat Tube Length  406  430  480  533
(B) Top Tube Effective  585  595  615  630
(C) Head Tube Angle  71°  71.5°  71.5°  71.5°
(D) Seat Tube Angle  73.5°  73°  73°  73°
(E) Wheelbase  1086  1088  1107  1122
(F) Rear Center  445  445  445  445
(G) BB Drop  60  60  60  60
(H) Head Tube Length  110  110  110  120
