FEATURES

  • RST Capa T26 Suspension Fork with Preload Adjustment
  • Full 24 Speed Gear System now with Trigger Shifters
  • New Bike Weight of only 13.08kg (With Pedals)

SPECIFICATIONS

Frame Race Tech 1, JR Race Geometry
Sizes 1 Size Only
Fork RST Capa T26, Preload
Chainwheel SR SUNTOUR XCT 42/32/22T
Bottom Bracket 5pc
F. Derailleur SRAM 3.0
R. Derailleur SRAM X4 8 Speed
Shifter SRAM X4 Trigger
Brake Levers Tektro Alloy
Brakes Tektro Alloy V-Brake
Cassette SRAM PG 820, 11-32
Rims Weinmann ZAC 19, Double Wall, 32H
Tires Kenda 26 x 1.95″
Pedals Alloy Cage
Handlebar Alloy Lightweight Flat, 540mm
Stem Alloy Forged, 60mm
Seatpost Alloy Micro-Adjust
Seat Momsen JR Race
Headset Threadless Ahead
Colors Matte Black w/Red Details
Chain KMC 8-Speed
Hubset Alloy, Quick Release, 32h
Spokes Stainless, 14G
Grips Kraton
Weight 13.08kg (With Pedals)

GEOMETRY

SIZE JR 100
(A) Seat Tube Length  356
(B) Top Tube Effective  520
(C) Head Tube Angle  72°
(D) Seat Tube Angle  75°
(E) Wheelbase  –
(F) Rear Center  415
(G) BB Drop  53
(H) Head Tube Length  90
