FEATURES

  • Super Low Weight – Just 8.76kg Complete – lighter than Dad’s
  • Triple Butted Alloy Frame – lighter than Dad’s
  • Superlight Alloy Fork – lighter and more control
  • SRAM 6 Speed “GearBox” – enough to get up hills
  • Shimano REVOSHIFT shifters – easy to use
  • Shimano HG20 14-28T Cassette
  • Alloy Rims, Stainless Steel Spokes, Kenda Small Block Eight Tyres

SPECIFICATIONS

Frame Triple Butted Junior Race Series
Sizes 20″ Wheel
Fork Custom Junior Alloy Superlight
Chainwheel Junior 40T with Chainguard
Bottom Bracket Semi Integrated
F. Derailleur N/A
R. Derailleur Shimano 6 Speed for 20”
Shifter RevoShift RS35
Brake Levers Junior Alloy
Brakes Tektro Alloy
Cassette Shimano HG20 11-28
Rims Alloy, 20”, 32H
Tires Kenda Small Block Eight, 20 x 1.75”
Pedals Platform
Handlebar Junior Alloy Lightweight
Stem Junior Alloy Lightweight
Seatpost Alloy Micro-Adjust
Seat Momsen Junior Race
Headset Threadless Ahead
Colors Race Silver
Chain KMC 6-Speed
Hubset Alloy, 32h
Spokes Stainless Steel
Grips Junior Race
Weight 8.76kg

GEOMETRY

SIZE 20″ Wheel
(A) Seat Tube Length  258
(B) Top Tube Effective  440
(C) Head Tube Angle  72°
(D) Seat Tube Angle  73.5°
(E) Wheelbase  865
(F) Rear Center  375
(G) BB Drop  10
(H) Head Tube Length  105
