FEATURES

  • Race Tech 2 Alloy Butted Frame – Proven 29er geometry and custom lightweight alloy tubing – New 15” Small size option
  • Rockshox XC30 Air Damped Suspension Fork with Turnkey Lockout – Air damping for improved adjustability and less weight – Turnkey lockout for on/off function
  • Alex/Momsen Tubeless Ready Rims – Convert to Tubeless with less hassle – Improved performance with less weight
  • Shimano® M396 Hydraulic Disc Brakes – Excellent braking performance and reliability
  • High Spec Shimano® 27 Speed Gear System – Deore rear derailleur with wide 12-36 rear cassette
  • Shimano® Centerlock Hubs – High spec hubs – Reliable performance with solid disc rotor interface
Image module

SPECIFICATIONS

Frame Race Tech 2, Alloy 6061 Butted Tubeset
Sizes Small, Medium, Large, X-Large
Fork RockShox XC30 Air, Turnkey Lockout, 100mm
Rear Shock N/A
Chainwheel Shimano M521 44/32/22T Octalink
Bottom Bracket Shimano Octalink
F. Derailleur Shimano Alivio
R. Derailleur Shimano Deore
Shifter Shimano Alivio Trigger
Brake Levers Shimano M396 Hydraulic
Brakes Shimano M396 Hydraulic
Cassette Shimano HG300-9, 11-36T
Rims Alex / Momsen Tubeless Ready, 32H
Tires Kenda Honey Badger XC Pro, 29×2.05
Pedals Alloy Cage
Handlebar Alloy Flat Top 29er, 700mm
Stem Alloy Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Momsen Custom
Headset Alloy Threadless
Colors Race Grey w/Orange Details
Chain KMC 9 Speed
Hubset Shimano Centerlock, 32H
Spokes Stainless Butted with Alloy Nipples
Grips Silicone Race
Weight Small: 12.93kg (Excl. Pedals)

GEOMETRY

SIZE SMALL MEDIUM LARGE X-LARGE
(A) Seat Tube Length  380  430  480  533
(B) Top Tube Effective  580  595  615  630
(C) Head Tube Angle  71°  71.5°  71.5°  71.5°
(D) Seat Tube Angle  73°  73°  73°  73°
(E) Wheelbase  1083  1088  1107  1122
(F) Rear Center  450  455  455  455
(G) BB Drop  60  60  60  60
(H) Head Tube Length  110  110  110  120
