FEATURES

  • New 6069 Alloy Butted Frame – Custom 6069 alloy tubing – Revised 29er frame design with ITB (Integrated Toptube Bag)
  • ITB (Integrated Toptube Bag) – Exclusive design allows easy attachment of Momsen Design accessory bag – Easy access for all your accessories
  • Rockshox 30 Gold Air Damped Suspension Fork with Remote Lockout – Alloy stanchions and air damping for improved adjustability and less weight – Handlebar actuated remote lockout for on/off function
  • Stan’s ZTR Rapid Tubeless Ready Rims – Lightweight and designed for tubeless – The market leader in tubeless rim technology
  • Kenda SCT (Sealant Compatible Tubeless) Tyres – Designed for tubeless – No upgrades needed
  • High Spec Shimano® 20 Speed Gear System – XT rear derailleur with wide 12-36 rear cassette and 2 x 10 gearing

SPECIFICATIONS

Frame Race Tech 2, Alloy 6069 Butted Tubeset w/ITB Feature
Sizes Small, Medium, Large, X-Large
Fork RockShox 30 Gold Air w/Remote Poploc,100mm
Rear Shock N/A
Chainwheel Shimano SLX 38/24T
Bottom Bracket Shimano Hollowtech
F. Derailleur Shimano Deore
R. Derailleur Shimano XT
Shifter Shimano Deore Trigger
Brake Levers Shimano M396 Hydraulic Disc
Brakes Shimano M396 Hydraulic Disc
Cassette Shimano HG50, 11-36T
Rims Stan’s ZTR Rapid 29er Tubeless Ready, 32H
Tires Kenda Honey Badger XC Pro, 29×2.05 SCT Tubeless
Pedals Alloy Cage
Handlebar Alloy Flat Top 29er, 700mm
Stem Alloy Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Selle Royal Seta S1
Headset Alloy Taper
Colors Gloss Grey w/ Red Details
Chain KMC 10 Speed
Hubset Shimano Centerlock, 32H
Spokes Stainless Butted with Alloy Nipples
Grips Silicone Race
Weight Large: 12.27kg (Excl. Pedals)

GEOMETRY

SIZE SMALL MEDIUM LARGE X-LARGE
(A) Seat Tube Length  380  430  480  533
(B) Top Tube Effective  580  595  615  630
(C) Head Tube Angle  71°  71.5°  71.5°  71.5°
(D) Seat Tube Angle  73.5°  73°  73°  73°
(E) Wheelbase  1085  1089  1109  1124
(F) Rear Center  440  440  440  440
(G) BB Drop  60  60  60  60
(H) Head Tube Length  110  110  120  130
