FEATURES

  • Triple Butted Superlight Alloy Frame – The Lightest 24” frame we could make – Butting means we add material where it is needed and remove where it is not
  • SR Suntour XCR Air Damped Suspension Fork – Air damping means you can fine tune the fork for different rider weights – Improved control and adjustability
  • Shimano® 24 Speed Gear System – More gearing means more options when tackling challenging terrain
  • Alex/Momsen Tubeless Ready Rims – Convert to Tubeless with less hassle – Improved performance with less weight
  • Kenda Folding Bead Tyres – Folding bead tyres convert to tubeless easier and are lighter
  • Tektro Hydraulic Disc Brakes – More control via improved braking performance
Image module

SPECIFICATIONS

Frame Triple Butted Junior Race Series
Sizes 24” Wheel
Fork SR Suntour XCR Air, Hydraulic Lockout, 63mm Travel
Rear Shock N/A
Chainwheel SR Suntour XCT-JR 42/32/22T
Bottom Bracket Cartridge
F. Derailleur Shimano M310 Dual Pull
R. Derailleur Shimano Acera 8 Speed
Shifter Shimano Acera Trigger w/ Optical Gear Display
Brake Levers Tektro Hydraulic Disc
Brakes Tektro Hydraulic Disc
Cassette Shimano HG31, 11-34T
Rims Alex/Momsen Tubeless Ready, 24”, 32H
Tires Kenda Small Block Eight, 24 x 1.95”
Pedals Platform
Handlebar Junior Alloy Lightweight
Stem Junior Alloy Lightweight
Seatpost Alloy Micro-Adjust
Seat Momsen Junior Race
Headset Threadless
Colors Race Yellow / Cyan
Chain KMC 8 Speed
Hubset Alloy Disc, 32H, Quick Release
Spokes Stainless Steel
Grips Junior Race
Weight 10.89kg (Excl. Pedals)

GEOMETRY

SIZE 1 SIZE
(A) Seat Tube Length  309
(B) Top Tube Effective  526
(C) Head Tube Angle  72°
(D) Seat Tube Angle  71°
(E) Wheelbase  967
(F) Rear Center  416
(G) BB Drop  15
(H) Head Tube Length  102
