FEATURES

  • Race Tech 2 Alloy Butted Frame – Custom lightweight 15.5” Size Alloy frame with butted tubing to reduce weight
  • Rockshox XC30 Air Damped Suspension Fork – Air damping means you can fine tune the fork for different rider weights – Improved control and adjustability
  • Shimano® 27 Speed Gear System – More gearing means more options when tackling challenging terrain
  • Alex/Momsen Tubeless Ready Rims – Convert to Tubeless with less hassle – Improved performance with less weight
  • Tektro Hydraulic Disc Brakes – More control via improved braking performance
Image module

SPECIFICATIONS

Frame Race Tech 2, Alloy 6061 Butted Tubeset
Sizes 15.5” Junior
Fork RockShox XC30 Air, 80mm Travel
Rear Shock N/A
Chainwheel Truvativ E400, 44/32/22T
Bottom Bracket Cartridge Type
F. Derailleur Shimano M310
R. Derailleur Shimano Deore 9-Speed
Shifter Shimano Acera Trigger
Brake Levers Tektro Hydraulic Disc
Brakes Tektro Hydraulic Disc
Cassette Shimano HG200-9, 11-34T
Rims Alex/Momsen Tubeless Ready, 32H
Tires Kenda Small Block Eight, 26×1.95”
Pedals Platform
Handlebar Alloy Lightweight Flat, 580mm
Stem Alloy Forged, 75mm
Seatpost Alloy Micro-Adjust
Seat Momsen Junior Race
Headset Threadless Ahead
Colors Fast Black
Chain KMC 9 Speed
Hubset Alloy w/Quick Release, 32h
Spokes Stainless Steel
Grips Junior Race
Weight 11.59kg (Excl. Pedals)

GEOMETRY

SIZE 1 SIZE
(A) Seat Tube Length  394
(B) Top Tube Effective  559
(C) Head Tube Angle  71.5°
(D) Seat Tube Angle  74°
(E) Wheelbase  1024
(F) Rear Center  415
(G) BB Drop  40
(H) Head Tube Length  100
