FEATURES

  • Race proven, Suspension frame with Alloy Front / Carbon Rear – Lightweight 6069 alloy front triangle matched to a carbon rear triangle – Offers 80mm of efficient suspension travel
  • ITB (Integrated Toptube Bag) – Exclusive design allows easy attachment of Momsen Design accessory bag – Easy access for all your accessories
  • High Spec Shimano® XT/SLX 20 Speed Gear System – XT rear derailleur – XT crankset with wide 12-36 rear cassette and 2 x 10 gearing
  • Fox Float CTD 29er Fork with 15mm Thru-Axle – High end 29er fork with 100mm travel – 15mm Lowers – CTD Adjust
  • Fox Float CTD Rear Shock – 3 settings to optimize your ride. Climb, trail or descend
  • Stan’s ZTR Rapid Tubeless Ready Rims – Lightweight and designed for tubeless – The market leader in tubeless rim technology
  • Kenda SCT (Sealant Compatible Tubeless) Tyres Designed for tubeless – No upgrades needed
Image module

SPECIFICATIONS

Frame Alloy Front Triangle, Carbon Rear Triangle, 80mm Rear Wheel Travel
Sizes Small, Medium, Large, X-Large
Fork FOX Float CTD, 100mm Travel, 15mm Thru-Axle
Rear Shock FOX Float CTD Rear Shock
Chainwheel Shimano XT, 38/24T
Bottom Bracket Shimano Pressfit
F. Derailleur Shimano SLX Direct Mount
R. Derailleur Shimano XT
Shifter Shimano Deore Trigger
Brake Levers Shimano M615 Hydraulic
Brakes Shimano M615 Hydraulic
Cassette Shimano HG50-10, 11-36T
Rims Stan’s No Tubes ZTR Rapid Tubeless Ready, 32H
Tires Kenda Honey Badger XC Pro, 29×2.05 SCT Tubeless
Pedals N/A
Handlebar Alloy Flat Top 29er, 700mm
Stem Alloy Forged, 31.8mm Oversize
Seatpost Alloy Micro-Adjust
Seat Selle Royal Seta S1
Headset Alloy Taper
Colors Grey w/Gold, Black and White Details
Chain KMC 10 Speed
Hubset Shimano Deore, 15mm Front, 142 x 12mm Rear, 32H
Spokes Stainless Butted with Alloy Nipples
Grips Silicone Race
Weight 12.35kg (Medium, excl. Pedals)

GEOMETRY

SIZE SMALL MEDIUM LARGE XL
(A) Seat Tube Length  406  432  483  533
(B) Top Tube Effective  570  595  615  640
(C) Head Tube Angle  70.5°  70.5°  70.5°  70.5°
(D) Seat Tube Angle  73.5°  73.5°  73.5°  73.5°
(E) Wheelbase  1077  1102  1122  1146
(F) Rear Center  440  440  440  440
(G) BB Drop  40  40  40  40
(H) Head Tube Length  105  115  125  135
(I) Reach  397  418.8  436  456
(J) Stack  585  595  604  614
