FEATURES

• 2017 RaceTech TWO Alloy Frame with exclusive LSG design
• Integrated Toptube Box ( I.T.B ) Feature – allows on-bike storage of key marathon/stage-race essentials
• SR Suntour XCR 32 Air Fork with Lockout and Rebound Adjustment
• Shimano 3 x 9 Altus Drivetrain with Shimano 11-34T Cassette
• Shimano M315 Hydraulic Disc Brakes
• Shimano TX Series Front and Rear Hubs with Centerlock
• CST Jack Rabbit 29 x 2.1 27tpi Wire Bead Tyres

SPECIFICATIONS

Sizes	Small, Medium, Large, X-Large
Frame	2017 RaceTech TWO Alloy, Exclusive LSG Design, Integrated Toptube Box ( I.T.B ), Tapered Headtube Profile
Fork	SR Suntour XCR32, 100mm Travel, Air Adjust, Lockout with Rebound Adjust
Rear Shock	Nil
Chainwheel	Shimano M351 44/32/22T for 9 Speed
Bottom Bracket	Cartridge Type
F. Derailleur	Shimano M370 Altus
R. Derailleur	Shimano M370 Altus for 9 Speed
Shifter	Shimano M370 Altus Trigger for 9 Speed
Brake Levers	Shimano M315 Hydraulic
Brakes	Shimano M315 Hydraulic / SM-RT10 Centerlock Rotors / 160mm Front and Rear
Cassette	Shimano HG200-9 11-34T for 9 Speed
Rims	Weinmann XM260 Alloy Doublewall, Custom Decal, 32H
Tires	CST Jack Rabbit, 27tpi Wire Bead, 29 x 2.10 Front and Rear
Pedals	Steel Cage MTB Platform
Handlebar	Momsen Oversize Flat Wide Alloy, 700mm, 6 Degree Sweep, 31.8mm Oversize
Stem	Momsen Alloy Forged , 31.8mm Oversize ( S – 70mm, M – 80mm, L – 90mm, XL – 100mm )
Seatpost	Momsen Alloy, 31.6mm
Seat	Momsen 2017 Custom, Satin Steel Rail
Headset	Integrated Type
Colors	Bright Blue/Dark Grey or Bright Yellow/Dark Grey
Chain	KMC Z99 for 9 Speed
Hubset	Shimano TX Centerlock – Front and Rear
Spokes	Stainless Butted with Brass Nipples
Grips	Kraton MTB Closed End

GEOMETRY

SIZE	SMALL	MEDIUM	LARGE	XL
(A) Seat Tube Length	380	430	480	533
(B) Top Tube Effective	590	610	630	650
(C) Head Tube Angle	70.5°	70.5°	70.5°	70.5°
(D) Seat Tube Angle	73.5°	73°	73°	73°
(E) Wheelbase	1099	1113	1134	1154
(F) Rear Center	450	450	450	450
(G) BB Drop	60	60	60	60
(H) Head Tube Length	110	110	120	130
(I ) Reach	408	423	440	457
