FEATURES

• 2016 Race Tech 2 Alloy 6061 Butted Tubing with Tapered Headtube
• 4 Sizes Available – we have added an XL size for larger riders
• Shimano® XT 2×10 Speed Drivetrain – the most requested option
• RockShox RECON Silver Air Suspension Fork – Solo Air with 100mm Travel
• RockShox POPLOC Remote Lockout – on/off control of suspension
• Stan’s ZTR RAPID 29er Tubeless Ready Rims – Patented Bead Socket Technology
• Oversize TAPER Headtube Design – Upgraded Headset and Taper Steerer Fork

SPECIFICATIONS

Frame	2016 Race Tech 2, Alloy 6061 Butted Tubing, Taper Headtube
Sizes	Small, Medium, Large, X-Large
Fork	RockShox RECON Silver Air, Remote Lockout, 100mm
Rear Shock	N/A
Chainwheel	Shimano XT M785 38/24T
Bottom Bracket	Shimano Hollowtech
F. Derailleur	Shimano XT M785 Dual Pull
R. Derailleur	Shimano XT M786 Shadow Plus
Shifter	Shimano SLX M670 for 10 Speed
Brake Levers	Shimano M506 Hydraulic Disc
Brakes	Shimano M506 Hydraulic Disc, Shimano SM-RT30 Rotors, 160mm Front and Rear
Cassette	Shimano HG50 11-36T
Rims	Stan’s ZTR RAPID 29er Tubeless Ready, 32H
Tires	Vee Tire Co. RAIL Custom Logo, Wire Bead, Front: 29 x 2.25, Rear 29 x 1.95
Pedals	Alloy Cage MTB
Handlebar	Alloy Flat, 31.8 Oversize, 700mm
Stem	Alloy Forged, 31.8mm Oversize
Seatpost	Alloy Micro-Adjust 3D Forged
Seat	Momsen Custom, Embossed Graphic, ED Rail
Headset	Alloy Taper
Colors	Gloss Black / Orange
Chain	KMC 10 Speed
Hubset	Shimano RM35, Centerlock Disc, 32H
Spokes	Stainless
Grips	Silicone Race

GEOMETRY

SIZE	SMALL	MEDIUM	LARGE	X-LARGE
(A) Seat Tube Length	380	430	480	533
(B) Top Tube Effective	580	595	615	630
(C) Head Tube Angle	71°	71.5°	71.5°	71.5°
(D) Seat Tube Angle	73°	73°	73°	73°
(E) Wheelbase	1083	1088	1107	1122
(F) Rear Center	450	455	455	455
(G) BB Drop	60	60	60	60
(H) Head Tube Length	110	110	110	120
