FEATURES

• 2017 RaceTech TWO Alloy Frame with exclusive LSG design
• Integrated Toptube Box ( I.T.B ) Feature – allows on-bike storage of key marathon/stage-race essentials
• SR Suntour XCR 32 RL-R Air Fork with Remote Lockout and Rebound Adjustment
• Shimano 3 x 9 Acera Drivetrain with Shimano 12-36T Cassette
• Shimano M365 Hydraulic Disc Brakes
• Shimano M33 Front and Rear Hubs with Centerlock
• CST Jack Rabbit 29 x 2.1 27tpi Wire Bead Tyres

SPECIFICATIONS

Sizes	Small, Medium, Large, X-Large
Frame	2017 RaceTech TWO Alloy, Exclusive LSG Design, Integrated Toptube Box ( I.T.B ), Tapered Headtube Profile
Fork	SR Suntour XCR32 RL-R, 100mm Travel, Air Adjust, Remote Lockout with Rebound Adjust
Rear Shock	Nil
Chainwheel	Shimano M351 44/32/22T for 9 Speed
Bottom Bracket	Shimano BB-UN26 Cartridge
F. Derailleur	Shimano M370 Altus
R. Derailleur	Shimano M3000 Acera for 9 Speed
Shifter	Shimano M3000 Acera Trigger for 9 Speed
Brake Levers	Shimano M365 Hydraulic
Brakes	Shimano M365 Hydraulic / SM-RT10 Centerlock Rotors / 160mm Front and Rear
Cassette	Shimano HG300-9 12-36T for 9 Speed
Rims	Weinmann XM260 Alloy Doublewall, Custom Decal, 32H
Tires	CST Jack Rabbit, 27tpi Wire Bead, 29 x 2.10 Front and Rear
Pedals	Alloy Cage MTB Platform
Handlebar	Momsen Oversize Flat Wide Alloy, 700mm, 6 Degree Sweep, 31.8mm Oversize
Stem	Momsen Alloy Forged , 31.8mm Oversize ( S – 70mm, M – 80mm, L – 90mm, XL – 100mm )
Seatpost	Momsen Alloy, 31.6mm
Seat	Momsen 2017 Custom, Satin Steel Rail
Headset	Integrated Type
Colors	Race Blue / Dark Grey
Chain	KMC X9 for 9 Speed
Hubset	Shimano RM33 Centerlock – Front and Rear
Spokes	Stainless Butted with Brass Nipples
Grips	Kraton Composite Lock-On

GEOMETRY

SIZE	SMALL	MEDIUM	LARGE	XL
(A) Seat Tube Length	380	430	480	533
(B) Top Tube Effective	590	610	630	650
(C) Head Tube Angle	70.5°	70.5°	70.5°	70.5°
(D) Seat Tube Angle	73.5°	73°	73°	73°
(E) Wheelbase	1099	1113	1134	1154
(F) Rear Center	450	450	450	450
(G) BB Drop	60	60	60	60
(H) Head Tube Length	110	110	120	130
(I ) Reach	408	423	440	457
