FEATURES

• 2017 RaceTech SL 6000 Series Alloy Frame with Internal Downtube Routing
• Integrated Toptube Box ( I.T.B ) Feature – allows on-bike storage of key marathon/stage-race essentials
• RockShox 30 Silver TK 100mm with POPLOC Remote
• Shimano 2 x 10 Drivetrain
• Shimano XT Rear Derailleur
• Shimano RM35 Front and Rear Hubs with Centerlock
• Alex DP21 Tubeless Ready Rims
• Vee Tire Co. Rail Tracker 29 x 2.2 Skinwall Tyres

SPECIFICATIONS

Sizes	Small, Medium, Large, X-Large
Frame	2017 RaceTech SL 6000 Series Alloy, Downtube Internal Cable Routing, SideSwing Compatibility, Integrated Toptube Box ( I.T.B )
Fork	RockShox 30 Silver TK, 100mm Travel, Air Adjust, POPLOC Remote Lockout
Rear Shock	Nil
Chainwheel	Shimano M627 38/24T for 10 Speed
Bottom Bracket	Shimano BB52 External
F. Derailleur	Shimano M617 SideSwing 2x
R. Derailleur	Shimano XT Shadow Plus for 10 Speed
Shifter	Shimano SLX Trigger for 10 Speed
Brake Levers	Shimano M365 Hydraulic
Brakes	Shimano M365 Hydraulic / SM-RT30 Centerlock Rotors / 160mm Front and Rear
Cassette	Shimano HG50 11-36T for 10 Speed
Rims	Alex DP21 Tubeless Ready, Custom Decal, 32H
Tires	Vee Tire Co. Rail Tracker Custom Logo, Skinwall, 72tpi Wire Bead, 29 x 2.20 Front and Rear
Pedals	Alloy Cage MTB Platform
Handlebar	Momsen Oversize Flat Wide Alloy, 700mm, 6 Degree Sweep, 31.8mm Oversize
Stem	Momsen Alloy Forged , 31.8mm Oversize ( S – 70mm, M – 80mm, L – 90mm, XL – 100mm )
Seatpost	Momsen Alloy, 31.6mm
Seat	Momsen 2017 Custom, Satin Steel Rail
Headset	Integrated Taper
Colors	Navy/Orange
Chain	KMC X10 for 10 Speed
Hubset	Shimano RM35 Centerlock – Front and Rear
Spokes	Stainless Butted with Brass Nipples
Grips	Kraton Composite Lock-On

GEOMETRY

SIZE	SMALL	MEDIUM	LARGE	XL
(A) Seat Tube Length	380	430	480	533
(B) Top Tube Effective	580	595	615	630
(C) Head Tube Angle	71°	71.5°	71.5°	71.5°
(D) Seat Tube Angle	73°	73°	73°	73°
(E) Wheelbase	1083	1088	1107	1122
(F) Rear Center	450	455	455	455
(G) BB Drop	60	60	60	60
(H) Head Tube Length	110	110	110	120
