  • New 20″ Wheel Size JR Race Alloy Frame
  • Shimano® RevoShift Gear Selector – Intuitive and User Friendly for Young Kids
  • Tektro Lightweight Alloy V-Brakes – Safety first
  • Alloy Crankset with Dual Chainguard – Light and Dual Chainguard ensures chain does not derail during offroad adventures
  • Shimano® 6 Speed Frewheel – 14-28T
  • Weinmann Alloy DA19 Alloy Rims – Light and Strong
  • Alloy Handlebar and Stem – Light and Strong
Image module

SPECIFICATIONS

Frame JR Race, 20” Wheel, Alloy Tubing
Sizes 20” Wheel
Fork SR Suntour M3010, 40mm Travel, Preload Adjust
Rear Shock N/A
Chainwheel Alloy 36T with Double Chainguard
Bottom Bracket Semi Integrated
F. Derailleur N/A
R. Derailleur Shimano 6 Speed for 20”
Shifter Shimano RevoShift RS35
Brake Levers Tektro Alloy
Brakes Tektro Alloy V-Brake
Cassette Shimano TZ20, 14-28T
Rims Weinmann DA19, 20”, 32H
Tires All Terrain 20 x 2.0
Pedals MTB Platform
Handlebar Junior Alloy Lightweight, 520mm
Stem Junior Alloy Lightweight, 60mm
Seatpost Alloy Micro-Adjust
Seat Momsen Junior Race
Headset Threadless
Colors Race Orange
Chain KMC 6 Speed
Hubset Alloy, 32H
Spokes Stainless
Grips Junior Race
Weight 10.9kg (with Pedals)

GEOMETRY

SIZE 1 SIZE
(A) Seat Tube Length  305
(B) Top Tube Effective  447
(C) Head Tube Angle  71°
(D) Seat Tube Angle  70°
(E) Wheelbase  850
(F) Rear Center  370
(G) BB Drop  0
(H) Head Tube Length  110
