FEATURES

  • New 24″ Wheel Size JR Race Alloy Frame – Modelled on the popular JR100 26″ bike but adjusted for 24″ Wheels
  • SR Suntour XCT-JR Suspension Fork – Reputable brand and Preload Adjustment for fine tuning
  • Shimano® M310 Trigger Shifters – Big Bike performance on a JR bike – Indexed, User-Friendly gear changes
  • Tektro MD-300 Mechanical Disc Brakes – Reputable brand and Safety-First braking
  • Alloy Crankset with Triple Chainrings – 42/32/22 Tooth / Wide Range Gearing
  • Shimano® HG20-7 Cassette – High End Feature with Cassette Freewheel Body / 12-32 Wide Range Gearing
  • Alloy Oversize 31.8mm Cockpit – Oversize Design for Strength, Alloy for Lightweight
  • Weinmann Alloy DA19 Alloy Rims – Light and Strong
Image module

SPECIFICATIONS

Frame New JR Race, Race Tech 1 Aluminium
Sizes 24” Wheel
Fork SR Suntour XCT-JR, Preload Adjust
Rear Shock N/A
Chainwheel Alloy Forged, 42/32/22
Bottom Bracket VP Cartridge
F. Derailleur Shimano M310
R. Derailleur Shimano Altus 7-Speed
Shifter Shimano M310 Trigger
Brake Levers Tektro MD-300 Mechanical Disc
Brakes Tektro Alloy for Disc
Cassette Shimano HG20, 11-32T
Rims Weinmann DA19, 24”, 32H, Alloy
Tires All Terrain, 24 x 1.95
Pedals MTB Platform
Handlebar Alloy Oversize 31.8, 560mm
Stem Alloy Oversize 31.8, 60mm Extension
Seatpost Alloy Micro-Adjust
Seat Momsen Junior Race
Headset Integrated Threadless
Colors Race Orange
Chain KMC 7 Speed
Hubset Alloy Disc, 32H, Quick Release
Spokes Stainless
Grips Junior Race
Weight 12.9kg (with Pedals)

GEOMETRY

SIZE 1 SIZE
(A) Seat Tube Length  305
(B) Top Tube Effective  503
(C) Head Tube Angle  71°
(D) Seat Tube Angle  71°
(E) Wheelbase  953
(F) Rear Center  415
(G) BB Drop  15
(H) Head Tube Length  120
