FEATURES

  • Juvenile Specific Carbon Race Frame – Monocoque construction – Lightweight, stiff and responsive
  • Juvenile Specific Carbon Race Fork – Superlight – Disc-specific – Lightweight, stiff and responsive
  • Shimano® 8-speed Gear System – More gears means easier to ride over varied terrain
  • Tektro Hydraulic Disc Brakes – Improved performance and braking – Smaller brake lever for small hands
Image module

SPECIFICATIONS

Frame Carbon Junior Race Series with postmount disc tab
Sizes 20” Wheel
Fork Carbon Junior Superlight Disc
Rear Shock N/A
Chainwheel Junior 32T w/ Dual Chainguard
Bottom Bracket Semi Integrated
F. Derailleur N/A
R. Derailleur Shimano Claris 8 Speed
Shifter Shimano Acera 8 Speed Trigger
Brake Levers Tektro Hydraulic Disc with Small Lever
Brakes Tektro Hydraulic Disc
Cassette Shimano HG20, 12-32T
Rims Alex ACE20 Alloy Double Wall, 20”, 32H
Tires Kenda Small Block Eight, 20 x 1.75
Pedals MTB Platform
Handlebar Junior Alloy Lightweight, 540mm
Stem Junior Alloy Lightweight, 60mm
Seatpost Alloy Micro-Adjust
Seat Momsen Junior Race Superlight
Headset Alloy Integrated Threadless
Colors Fast Black
Chain KMC 8 Speed
Hubset Alloy, 32H
Spokes Stainless
Grips Kraton
Weight 8.94kg (with Pedals)

GEOMETRY

SIZE 1 SIZE
(A) Seat Tube Length  300
(B) Top Tube Effective  437
(C) Head Tube Angle  70°
(D) Seat Tube Angle  70°
(E) Wheelbase  865
(F) Rear Center  385
(G) BB Drop  0
(H) Head Tube Length  98
