FEATURES

  • Triple Butted Superlight Alloy Frame – the Lightest 20” Frame we could make – butting means we add material where it is needed and remove where it is not
  • Lightweight Alloy Fork – Suspension Forks without damping are just heavy – a Rigid Alloy Fork is lighter and easier to control than a heavy pogo stick
  • Shimano® 6 speed Gear System – quality Gear System with intuitive RevoShift “twist style“ shifters
  • Lightweight and Strong Wheels – Double Wall Alloy rims mean these wheels can take a pounding – Alloy Hubs and Stainless Steel Spokes
Image module

SPECIFICATIONS

Frame Triple Butted Junior Race Series
Sizes 20” Wheel
Fork Custom Junior Alloy Superlight
Rear Shock N/A
Chainwheel Junior 32T w/ Chainguard
Bottom Bracket Semi Integrated
F. Derailleur N/A
R. Derailleur Shimano 6 Speed for 20”
Shifter Shimano RevoShift RS35
Brake Levers Junior Alloy
Brakes Tektro Alloy
Cassette Shimano HG20, 11-28T
Rims Weinmann DA19, 20“, 32H, Machined Braking Surface
Tires Kenda Small Block Eight, 20 x 1.75
Pedals MTB Platform
Handlebar Junior Alloy Lightweight, 540mm
Stem Junior Alloy Lightweight, 60mm
Seatpost Alloy Micro-Adjust
Seat Momsen Junior Race Superlight
Headset Threadless Alloy
Colors Race Red / Fresh White
Chain KMC 6 Speed
Hubset Alloy, 32H
Spokes Stainless
Grips Junior Race
Weight 8.4kg (with Pedals)

GEOMETRY

SIZE 1 SIZE
(A) Seat Tube Length  258
(B) Top Tube Effective  440
(C) Head Tube Angle  72°
(D) Seat Tube Angle  73.5°
(E) Wheelbase  865
(F) Rear Center  375
(G) BB Drop  10
(H) Head Tube Length  105
