FEATURES

  • New Junior Race Series 26″ Wheel Frame with Alloy Tubing
  • SR Suntour XCR Suspension Fork with Air Damping, Rebound Adjustment and 100mm of controlled travel
  • Shimano® 24 Speed Gear System
  • Tektro M290 Hydraulic Disc Brakes with Tektro Brake Rotors – Proven Performance
  • Shimano® TY701 Crankset and Shimano® Cartridge Bottom Bracket – Triple Chainring Design 42/34/24T
  • Shimano® HG200-8 Cassette with 12-32T Gearing
  • Alex DA16 Double Wall Alloy Rims – Light and Durable
Image module

SPECIFICATIONS

Frame Junior Race Series, Alloy Tubing
Sizes X-Small, Small
Fork SR Suntour XCR Air, Hydraulic Lockout, Rebound Adjust and 100mm Travel
Rear Shock N/A
Chainwheel Shimano TY701 42/34/24T
Bottom Bracket Shimano Cartridge
F. Derailleur Shimano M190 Dual Pull
R. Derailleur Shimano Altus 8 Speed
Shifter Shimano M310 Trigger w/ Optical Gear Display
Brake Levers Tektro M290 Hydraulic Disc
Brakes Tektro M290 Hydraulic Disc, Tektro Brake Rotors, 160mm Front and Rear
Cassette Shimano HG200-8, 12-32T
Rims Alex DA16 Double Wall Alloy, 32H
Tires Kenda Small Block Eight, 26 x 2.10, 60tpi, Folding Bead
Pedals Steel Cage MTB
Handlebar Junior Alloy Lightweight Flat, 31.8 Oversize, 560mm
Stem Junior Alloy Lightweight, 31.8 Oversize
Seatpost Alloy Micro-Adjust
Seat Momsen Junior Race Superlight
Headset Threadless Ahead
Colors Fast Black
Chain KMC 8 Speed
Hubset Alloy Disc, 32H, Quick Release
Spokes Stainless
Grips Kraton Comfort
Weight 12.99kg (with Pedals)

GEOMETRY

SIZE X-SMALL SMALL
(A) Seat Tube Length  356  394
(B) Top Tube Effective  545  560
(C) Head Tube Angle  71° 71°
(D) Seat Tube Angle  73°  73°
(E) Wheelbase  1020  1035
(F) Rear Center  424  424
(G) BB Drop  30  30
(H) Head Tube Length  110  110
