FEATURES

• 2017 RaceTech One Alloy Frame with Forged Dropout and Oversize Headtube
• Available in Small, Medium, Large Frame Sizes
• Suspension Fork with 63mm Travel and Mechanical Lockout Lever
• Shimano 21 Speed Gear System with Shimano TZ Freewheel
• Shimano EF41 Brake/Shifter Levers
• Alloy Rims with Alloy Quick Release Hubs Front and Rear
• Mechanical Disc Brakes – Front and Rear, 160mm Rotors
• Alloy Handlebar with Forged Alloy Stem

SPECIFICATIONS

Sizes	Small, Medium, Large
Frame	2017 RaceTech One Alloy 6000 Series with Forged Dropout and Oversize Headtube
Fork	HL-386A Suspension Fork with Mechanical Lockout, 63mm Travel, Disc Brake Version
Rear Shock	Nil
Chainwheel	Alloy Forged Crankarm, 42/34/24T for Triple
Bottom Bracket	Cartridge Type
F. Derailleur	Shimano TZ21
R. Derailleur	Shimano TZ50 for 21 Speed
Shifter	Shimano EF41 for 21 Speed
Brake Levers	Shimano, included with Shifter
Brakes	Mechanical Disc Type, 160mm Disc Rotors Front and Rear
Cassette	Shimano TZ21, 7 Speed
Rims	Alloy Doublewall Design, Custom Logo
Tires	H-5129 26 x 1.95, Wire Bead
Pedals	Metal Cage Platform MTB Type
Handlebar	Momsen Alloy Oversize, 660mm Riser Type, 31.8mm Oversize
Stem	Momsen Alloy Forged, 31.8mm Oversize
Seatpost	Alloy, 27.2mm
Seat	Momsen Comfort, Satin Steel Rail
Headset	Threadless Type
Colors	Matte Black
Chain	KMC Z50 for 21 Speed
Hubset	Alloy with Quick Release, Front and Rear
Spokes	Stainless Steel with Brass Nipples
Grips	Kraton MTB Type

GEOMETRY

SIZE	SMALL	MEDIUM	LARGE
(A) Seat Tube Length	380	430	480
(B) Top Tube Effective	550	565	580
(C) Head Tube Angle	71°	71°	71°
(D) Seat Tube Angle	74°	74°	74°
(E) Wheelbase	1045	1060	1076
(F) Rear Center	435	435	435
(G) BB Drop	40	40	40
(H) Head Tube Length	120	130	140
