FEATURES

  • 2017 RaceTech One Alloy Frame with Forged Dropout and Oversize Headtube
  • Available in Small and Medium Frame Sizes
  • Suspension Fork with 63mm Travel and Mechanical Lockout Lever
  • Shimano 21 Speed Gear System with Shimano TZ Freewheel
  • Shimano EF41 Brake/Shifter Levers
  • Alloy Rims with Alloy Quick Release Hubs Front and Rear
  • Mechanical Disc Brakes – Front and Rear, 160mm Rotors
  • Alloy Handlebar with Forged Alloy Stem
  • Lady Specific Comfort Saddle
Image module

SPECIFICATIONS

Sizes Small, Medium
Frame 2017 RaceTech One Alloy 6000 Series with Forged Dropout and Oversize Headtube
Fork HL-386A Suspension Fork with Mechanical Lockout, 63mm Travel, Disc Brake Version
Rear Shock Nil
Chainwheel Alloy Forged Crankarm, 42/34/24T for Triple
Bottom Bracket Cartridge Type
F. Derailleur Shimano TZ21
R. Derailleur Shimano TZ50 for 21 Speed
Shifter Shimano EF41 for 21 Speed
Brake Levers Shimano, included with Shifter
Brakes Mechanical Disc Type, 160mm Disc Rotors Front and Rear
Cassette Shimano TZ21, 7 Speed
Rims Alloy Doublewall Design, Custom Logo
Tires H-5129 26 x 1.95, Wire Bead
Pedals Metal Cage Platform MTB Type
Handlebar Momsen Alloy Oversize, 660mm Riser Type, 31.8mm Oversize
Stem Momsen Alloy Forged, 31.8mm Oversize
Seatpost Alloy, 27.2mm
Seat Momsen Lady Specific, Satin Steel Rail
Headset Threadless Type
Colors Matte Grey
Chain KMC Z50 for 21 Speed
Hubset Alloy with Quick Release, Front and Rear
Spokes Stainless Steel with Brass Nipples
Grips Kraton Ergonomic Type

GEOMETRY

SIZE SMALL MEDIUM
(A) Seat Tube Length  380  430
(B) Top Tube Effective  550  565
(C) Head Tube Angle  71°  71.5°
(D) Seat Tube Angle  74°  74°
(E) Wheelbase  1045  1060
(F) Rear Center  435  435
(G) BB Drop  40  40
(H) Head Tube Length  120  130
