FEATURES
• Signature Low Leverage Design (not dissimilar to our current VIPA RACE models )
• Monocoque Front Triangle with Internal Cable Routing (various cable routing options and covers provided )
• Carbon Seatstays and Chainstays with Boost 148 x 12 mm rear end
• Designed for both 2x and 1x Drivetrain Options
• Optional Internal Shimano®️ Di2 Battery holder – allowing for enclosed battery fitment whilst still allowing Dropper Seatpost compatibility
• Available in 4 frame sizes – S, M, L, XL
• Internal Cable Routing for Dropper Seatpost
• Seatpost Diameter : 31.6mm
• Bottom Bracket : Pressfit 92mm
VIPA TRAIL
FRAME KIT
IT’S TIME.
Riding styles and preferences are ever evolving and progressing. The all-new VIPA TRAIL with 120mm of supple, efficient and comfortable travel is the bike that not only heralds the change but also embraces the needs of those who love the DOWNS as much as the UPS. A bike that is just as comfortable at the sharp end of a Stage Race or Marathon event as it is railing berms or jumping drops on your gnarlier home trails. A bike that makes you feel younger and faster no matter the terrain!
MSRP: R26 650.00
GEOMETRY

| SIZE | SEATTUBE LENGTH | TOPTUBE EFFECTIVE | HEAD ANGLE | SEAT ANGLE | WHEELBASE | REAR CENTRE | BB DROP | HEADTUBE LENGTH | REACH | STACK |
| SMALL | 394 | 562 | 67.8 | 73.5 | 1105 | 440 | 39 | 95 | 384 | 589 |
| MEDIUM | 445 | 583 | 67.8 | 73.5 | 1128 | 440 | 39 | 105 | 405 | 599 |
| LARGE | 483 | 603 | 67.8 | 73.5 | 1149 | 440 | 39 | 115 | 422 | 608 |
| X-LARGE | 533 | 633 | 67.8 | 73.5 | 1180 | 440 | 39 | 125 | 450 | 618 |
